ME74A Robotic Fairway Mower

A pure-electric robotic mower for golf-course fairway maintenance — a fairway mower, not a greens mower. It cuts with three reel cutting units and combines positioning, environment perception and automatic operation, with a 1.88 m cutting width and a 10–60 mm cutting height range.

Cutting width
1.88m
Cutting height
10–60mm
Reel cutting units
3
See full specifications Ask about product and site fit
ME74A robotic fairway mower from a raised front angle: the complete machine with its wheels and the three reel cutting units
ME74A, studio image from a raised front angle. The whole machine is shown, including the wheels and the reel cutting units; nothing is cropped.

Features

What the ME74A does.

Cutting system
Three reel cutting units, each driven by its own brushless DC motor, with the cutting height adjustable from 10 to 60 mm.
Positioning and perception
Dual-antenna RTK positioning with virtual boundaries. 3D lidar, a full-colour camera and ultrasonic sensors for obstacle detection.
Automatic operation and cross-area travel
Automatic travel between the maintenance yard and the fairways, movement across areas, obstacle avoidance, and automatic return when it rains or a fault occurs, as described in the product literature. Routes and site fit are confirmed per course.
Battery and recharging
48 V / 450 Ah lithium iron phosphate battery. Automatic return to the charging station as described in the product literature; wired plug-in and wireless contactless charging options are listed.

Functions are as described in the product literature.

Images

ME74A, studio image from a raised front angle. The whole machine is shown, including the wheels and the reel cutting units; nothing is cropped.
ME74A robotic fairway mower from a raised front angle: the complete machine with its wheels and the three reel cutting units

ME74A, studio image from a raised front angle. The whole machine is shown, including the wheels and the reel cutting units; nothing is cropped.

Specifications

Technical specifications.

Specifications are from the ME74A product literature. Actual performance depends on turf conditions, slope, route, weather and the delivered configuration.

Cutting system
Cutting width1.88 m
Cutting height10–60 mm
Reel cutting units3
Reel diameter203.2 mm (8 in)
Reel driveIndependent brushless DC motors
Work rate
Rated mowing rate8,000 m²/hRated figure, not measured or guaranteed by NXTektal.
Rated area per charge60,000 m²Rated figure.
Rated run time on a full charge8–9 hRated figure.
Battery and charging
Battery typeLithium iron phosphate (LiFePO₄)
Battery rating48 V / 450 Ah
Rated charging time4.5 hThe charging configuration is to be confirmed.
ChargingWired plug-in and wireless contactless options are listed in the literatureConfiguration to be confirmed; neither option is assumed to be included.
Positioning and perception
PositioningDual-antenna RTK with virtual boundaries
Obstacle detection3D lidar, full-colour camera, ultrasonic sensors
Travel and drive
Maximum travel speed9 km/hMaximum travel speed, not a sustained mowing speed.
DriveThree independent drive motors
Steering and controlWide-angle rear-wheel steering with torque vectoring
TyresTurf tyres
Gradient
Maximum travel gradient60% (about 31°)Rated for travel only, not for mowing.
Maximum mowing gradient44% (about 24°)Rated for mowing.
Dimensions and weight
Length × width × height2.78 × 1.98 × 1.56 m
Weight950 kg
Protection and warranty
Ingress protectionIP65As marked in the product literature.
Warranty period2 yearsPer the product literature; scope and conditions are set by the delivery contract.
